M3 x 8 mm Flat Head 120° Phillips Machine Screw Steel Blue Zinc Plated
Why Choose MF12PM308Z?
MF12PM308Z is a M3 Flat 120 head Phillips drive screw with 8 mm length, featuring a Blue Zinc Plated Steel finish. Compared to alternative finishes in the same specification such as MF12PM308S (SUS304 Stainless Steel), MF12PM308B (Black Zinc Plated Steel), the Blue Zinc Plated Steel of MF12PM308Z offers moderate corrosion resistance with a distinctive blue iridescent appearance, commonly used in automotive assembly, machinery, and general industrial fastening. The Flat 120 head design ensures optimal load distribution across the mating surface, while the Phillips drive allows efficient torque transmission during installation. Each MF12PM308Z screw is manufactured to industry standards, RoHS compliant, and supplied with material test reports (MTR) for full quality traceability.
Payment Method: T/T & Paypal and other payment method
Shipment Method: Air Express , Air Freight, Sea Shippment
1. Order online directly, made payment via Paypal or bank transfer.
2. Superneer arrange production according to drawing,all demensions are within drawing specification.
3. Parts ready, ship to customer.
Frequently Asked Questions about MF12PM308Z
What is MF12PM308Z screw?
MF12PM308Z is a M3 Flat 120 head Phillips drive screw made of Blue Zinc Plated Steel, manufactured by Superneer Limited. It has a length of 8 mm and is commonly used in electronics, watches, precision instruments, and 3D printers.
What are the specifications of MF12PM308Z?
The MF12PM308Z screw features thread size M3, length of 8 mm, head type Flat 120 (head diameter 3.3-3.8 mm), drive type Phillips (drive size PH No.1), and is made of Blue Zinc Plated Steel.
What material is the MF12PM308Z screw made of?
The MF12PM308Z screw is made of Blue Zinc Plated Steel. Superneer provides material test reports (MTR) and RoHS compliance certificates for all products. Blue Zinc Plated Steel offers excellent corrosion resistance and mechanical strength.
What is the thread size of MF12PM308Z?
The MF12PM308Z screw has a M3 thread. This is a metric thread with M3 specification, commonly used in international applications following ISO standards.
What are MF12PM308Z screws used for?
MF12PM308Z Flat 120 head Phillips drive screws are used in electronics assembly, PCB mounting, precision instruments, watches, 3D printers, optical devices, medical equipment, and consumer products where reliable fastening with Flat 120 head aesthetics is required.
What is the MOQ and price for MF12PM308Z?
The minimum order quantity (MOQ) for MF12PM308Z is 10,000 pieces. The unit price is $0.014 USD for MOQ quantity. Larger quantities receive discounted pricing. Contact [email protected] for custom quotes.
What is the lead time and shipping for MF12PM308Z?
The lead time for MF12PM308Z is 15-25 days for production. Shipping to USA takes 5-15 days via sea freight, with shipping cost starting from $50 USD. Air freight is available for urgent orders. DDP and FOB terms are both available.
What is the inch equivalent of M3 thread?
The M3 thread is approximately equivalent to #6 (approx 6-32). When substituting metric screws with inch screws, always verify the actual diameter and pitch compatibility.
What head type does MF12PM308Z use and why?
The MF12PM308Z uses a Flat 120 head type. Flat 120 head provides a specific head design optimized for its intended application. This head type is selected based on the specific application requirements for load distribution, aesthetics, and accessibility.
How to choose the right screw size for my application?
To choose the right screw: 1) Determine the required thread size based on the tapped hole or nut; 2) Select the appropriate length based on the material thickness; 3) Choose the head type based on clearance and aesthetics; 4) Select the drive type based on torque requirements; 5) Choose the material based on environmental conditions. For MF12PM308Z (M3, 8 mm), ensure your application requires this specific size.
What is the difference between MF12PM308Z and similar parts?
MF12PM308Z uses Blue Zinc Plated Steel finish, while alternative variants in the same thread/length specification include MF12PM308S (SUS304 Stainless Steel), MF12PM308B (Black Zinc Plated Steel). The Blue Zinc Plated Steel of MF12PM308Z is specifically selected because it offers moderate corrosion resistance with a distinctive blue iridescent appearance, commonly used in automotive assembly, machinery, and general industrial fastening. This distinction makes MF12PM308Z the preferred choice when these properties align with your application requirements.
