M3.5 x 9 mm Pan Head Torx Machine Screw SUS304 Stainless Steel ISO 14583
Why Choose MPTM3509S?
MPTM3509S is a M3.5 Pan Head head Torx drive screw with 9 mm length, featuring a SUS304 Stainless Steel finish. Compared to alternative finishes in the same specification such as MPTM3509Z (Blue Zinc Plated Steel), MPTM3509B (Black Zinc Plated Steel), the SUS304 Stainless Steel of MPTM3509S offers superior corrosion resistance for outdoor, marine, and humid environments, excellent hygiene properties for food and medical equipment, and good mechanical strength at low cost relative to exotic alloys. The Pan Head head design ensures optimal load distribution across the mating surface, while the Torx drive allows efficient torque transmission during installation. Each MPTM3509S screw is manufactured to industry standards, RoHS compliant, and supplied with material test reports (MTR) for full quality traceability.
Payment Method: T/T & Paypal and other payment method
Shipment Method: Air Express , Air Freight, Sea Shippment
1. Order online directly, made payment via Paypal or bank transfer.
2. Superneer arrange production according to drawing,all demensions are within drawing specification.
3. Parts ready, ship to customer.
Frequently Asked Questions about MPTM3509S
What is MPTM3509S screw?
MPTM3509S is a M3.5 Pan Head head Torx drive screw made of SUS304 Stainless Steel, manufactured by Superneer Limited. It has a length of 9 mm and is commonly used in electronics, watches, precision instruments, and 3D printers.
What are the specifications of MPTM3509S?
The MPTM3509S screw features thread size M3.5, length of 9 mm, head type Pan Head (head diameter 6.64 - 7 mm), drive type Torx (drive size T15), and is made of SUS304 Stainless Steel.
What material is the MPTM3509S screw made of?
The MPTM3509S screw is made of SUS304 Stainless Steel. Superneer provides material test reports (MTR) and RoHS compliance certificates for all products. SUS304 Stainless Steel offers excellent corrosion resistance and mechanical strength.
What is the thread size of MPTM3509S?
The MPTM3509S screw has a M3.5 thread. This is a metric thread with M3.5 specification, commonly used in international applications following ISO standards.
What are MPTM3509S screws used for?
MPTM3509S Pan Head head Torx drive screws are used in electronics assembly, PCB mounting, precision instruments, watches, 3D printers, optical devices, medical equipment, and consumer products where reliable fastening with Pan Head head aesthetics is required.
What is the MOQ and price for MPTM3509S?
The minimum order quantity (MOQ) for MPTM3509S is 10,000 pieces. The unit price is $0.025 USD for MOQ quantity. Larger quantities receive discounted pricing. Contact [email protected] for custom quotes.
What is the lead time and shipping for MPTM3509S?
The lead time for MPTM3509S is 15-25 days for production. Shipping to USA takes 5-15 days via sea freight, with shipping cost starting from $50 USD. Air freight is available for urgent orders. DDP and FOB terms are both available.
What is the inch equivalent of M3.5 thread?
The M3.5 thread is approximately equivalent to #8 (approx 8-32). When substituting metric screws with inch screws, always verify the actual diameter and pitch compatibility.
What head type does MPTM3509S use and why?
The MPTM3509S uses a Pan Head head type. Pan Head head provides a specific head design optimized for its intended application. This head type is selected based on the specific application requirements for load distribution, aesthetics, and accessibility.
How to choose the right screw size for my application?
To choose the right screw: 1) Determine the required thread size based on the tapped hole or nut; 2) Select the appropriate length based on the material thickness; 3) Choose the head type based on clearance and aesthetics; 4) Select the drive type based on torque requirements; 5) Choose the material based on environmental conditions. For MPTM3509S (M3.5, 9 mm), ensure your application requires this specific size.
What is the difference between MPTM3509S and similar parts?
MPTM3509S uses SUS304 Stainless Steel finish, while alternative variants in the same thread/length specification include MPTM3509Z (Blue Zinc Plated Steel), MPTM3509B (Black Zinc Plated Steel). The SUS304 Stainless Steel of MPTM3509S is specifically selected because it offers superior corrosion resistance for outdoor, marine, and humid environments, excellent hygiene properties for food and medical equipment, and good mechanical strength at low cost relative to exotic alloys. This distinction makes MPTM3509S the preferred choice when these properties align with your application requirements.
